TS1071-2

TS1071-3

DTP 104,105

220

Benefits:

LED accent-lighting solution with a reasonable payback compared to conventional technologies
Suitable for food and fashion retailers
Available in a choice of black or white finish

Downloads:

Photometric LDT

Categories: Indoor Luminaires, Spotlighting, Track Mounted Tags: Factories, Industrial areas, Offices and public areas, Supermarkets, Warehouses

Description
Additional information

Description

EOC	Description	Colour, K	Track adaptor	COB	Power, W	FINISH	Beam Angle for the Reflector
700151452143	DTP104 LED033 27W 830 15DGR WH	3000	Global 3phase	Philips SLM G7	27	White	15
700151452144	DTP104 LED033 27W 830 25DGR WH	3000	Global 3phase	Philips SLM G7	27	White	25
700151452145	DTP104 LED033 27W 830 35DGR WH	3000	Global 3phase	Philips SLM G7	27	White	35
700151452146	DTP104 LED033 27W 830 15DGR BK	3000	Global 3phase	Philips SLM G7	27	Black	15
700151452147	DTP104 LED033 27W 830 25DGR BK	3000	Global 3phase	Philips SLM G7	27	Black	25
700151452148	DTP104 LED033 27W 830 35DGR BK	3000	Global 3phase	Philips SLM G7	27	Black	35

700151452149	DTP105 LED047 41W 830 15DGR WH	3000	Global 3phase	Philips SLM G7	41	White	15
700151452150	DTP105 LED047 41W 830 25DGR WH	3000	Global 3phase	Philips SLM G7	41	White	25
700151452151	DTP105 LED047 41W 830 35DGR WH	3000	Global 3phase	Philips SLM G7	41	White	35
700151452152	DTP105 LED047 41W 830 15DGR BK	3000	Global 3phase	Philips SLM G7	41	Black	15
700151452153	DTP105 LED047 41W 830 25DGR BK	3000	Global 3phase	Philips SLM G7	41	Black	25
700151452154	DTP105 LED047 41W 830 35DGR BK	3000	Global 3phase	Philips SLM G7	41	Black	35

Additional information

Type	DTP
Warranty period	5 years
Light source	Philips SLM G7
Driver	Track adaptor, driver included
Input voltage	220 – 240 V
Power factor	0,95
Power consuption tolerance	+/- 10%
Initial luminous flux	3300 lm (CRI830)
Initial LED luminaire efficacy	122 lm/W
Luminous flux tolerance	+/- 10%
Light Color	2700K, 3000K, 3500K, 4000K, 5000K
Color Rendering Index (CRI)	80 as a standard, 930,940 on request
Operating temperature range	0 to +35 °C
Median useful life L80B50	50000 hours
Reflector material	Faceted anodized aluminum
Optical cover/lens finish	Clear
Body material	Aluminium
Finishing	White or Black
Installation	Track mounted
Impact resistance	IK02
Ingress protection	IP20
Electrical safety	Class I or II
Application	• Shops • Show rooms • Meeting rooms • Circulation areas • Hospitality
