DKS 252

Benefits:

Entry level LED luminaire with lowest initial capital investment
Slim aesthetic design
Essential reducing energy consumption with Osram driver
Reliable quality
Energy effiency more than 100 lm/W
Special optic for pedesrian, bicycles roads (LB1) and pedestrian crossings (LB2)

Downloads:

Photometric IES

Description

Code	Type	Power, W	Initial luminous flux	Optic type	Weght kg
600151532001	DKS 252 LED065 62W 740 AS LB2	62	6500	Assymetrical LB2	3,5
600151532002	DKS 252 LED042 39W 740 AS LB2	39	4200	Assymetrical LB2	3,5
600151532003	DKS 252 LED065 62W 750 PC LB1	62	6500	Assymetrical LB1	3,5
600151532004	DKS 252 LED042 39W 750 PC LB1	39	4200	Assymetrical LB1	3,5

Driver built-in overvoltage protection – 6kV

Type	DKS 252
Light source	LED module
Driver	Driver included OSRAM
Mains voltage index	220-240 V / 50-60 Hz
Power	35-62W depending on type
Luminaire efficacy	>0,95
Luminous flux	4200-6500 lm depending on type
Color rendering index	70
Light Color	4000, 5000К
Maintenance of lumen output - L80F10	25°C – 50000 hours 10°C – 60000 hours
Maintenance	Opening with screw
Operating temperature range	-40 to +40 °C
Optic	LB1 – for pedestrian pavements, bycycles roads LB2 – for pedestrian crossings
Optical cover	Glass, flat
Body material	Housing: high-pressure, die-cast aluminium
Installation	Side-entry mounting: lateral entry Ø48/60mm Recommended mounting height: 4-7 m
Color	Grey
Impact resistance	IK08
Ingress protection	IP65
Electrical safety	Class I
Surge protection	6 kV
Application	• Small roads • Pedestrian pavements • Bicycles roads • Pedestrian roads
